E2EF-X3D1-M1TGJ Omron Proximity Sensor

Sensing Distance 2 mm Set distance 0 to 1.4 mm Differential travel 15% max Response frequency 200Hz Power supply voltage 10 to 30 VDC Leakage current 0.8 mA max Brand Omron Sensing Distance 3mm +- 10% Model Name/Number E2EF-X3D1-M1TGJ 0.3M Usage/Application Metal Sensing Standard sensing object Iron, 12 x 12 x 1 mm Response frequency 80 Hz Power supply voltage 10 to 30 VDC, ripple (p-p): 10% max. Cable Length 0.3 m Set Distance 0 to 2.1mm Differential Travel 15% max. of sensing distance Leakage Current 0.8 mA max. Switching Capacity 3 to 100 mA Residual Voltage 3 V max.(Load current: 100 mA max.)
