E30S4-500-6-L-5 Autonics Rotary Encoder

Material Stainless Steel Encoder Type Rotary Usage/Application Industrial Color Black Power Supply Voltage 12 -24 V Operating Temperature Range -10 ......... +70 C Weight (packed state) 80 g Model No. E30S4-500-6-L-5 Power supply 5 V Product Type Encoder Protection structure IP50 Max. response frequency 300 kHz Resolution 5000 P/R Weight 80 g E30S4-500-6-L-5 Shaft outer diameter : Ø4mm Max. response frequency : 300kHz Max. allowable revolution : 5000rpm Starting torque : Max. 20gf.cm(max. 0.00196N.m) Resolution : 500P/R Control output : Line Driver Power supply : 5VDC ±5%(ripple P-P: max. 5%) Connection type : Axial cable type Protection structure : IP50
