E32-CC200 Omron Fiber Optic Cable

Voltage 10-30V Brand Omron Type Fiber Optics Sensor Heads Light Source Red LED Interface IO-Link Model Number E32-CC200 Switching Frequency 200 Hz Switching Output PNP Housing Material Stainless Steel Degree of Protection IP67 Operating Temperature -40 to 125 Deg C No Load Supply Current 20 mA Supply voltage UB 10 ....... 30 V Device Short Name E32-CC200 Cable Type Fiber Optic Cable Application Industrial Accuracy 100 % Weight 36 g Temperature -40 .......... +70 C Housing M12 Product Type Cable Sensing method Diffuse reflective Shape Threaded Size M6 Application Object detection Features Small spot with lens Temperature range -40-70 °C Sensing distance 2100 mm Cable length 2 m Bending radius 25 mm Free cut c Material core Plastic Degree of protection (IP) IP67 Sensing surface orientation Top-view Material sheath Polyethylene
