E3F-DS30Y2 Clin Diffuse Photoelectric Sensor

Sensing Mode Diffuse Reflective Material ABS Make C-LIN Model No. E3F-DS30Y2 Thread Type M18 Detection Distance 5-30cm Response Time 1.5ms max IP Rating IP67 Response Frequency 300Hz Supply Voltage 6-36Vdc; 90-250Vac, 36Vac, 380Vac 50/60Hz E3F-DS30Y1 M18 30cm sensing AC two wires NO diffuse cylinder amplifier photoelectric switch sensors ? General Model number E3F-DS30 series External dimensions M18x1x67.5 Sensing method Diffuse reflective Detection distance 5-30cm Sensitivity adjustment Fixed Supply voltage 6-36Vdc; 90-250Vac, 36Vac, 380Vac 50/60Hz Rated output current N.P Type: 300mA max; A Type: 400mA; J type: 2A max (contact life: 100000 times) Sensing object Opaque object Response frequency 300Hz Response time 1.5ms max Light source Infrared LED (660 nm) Leakage current N.P Type: 20mA max; A Type: 1.7mA max Protection circuit DC: Reverse connection protection, Surge suppressor, Short-circuit protection AC: Surge suppressor
