E3FA-DP23 Omron Photoelectric Sensor

Material ABS Sensing Mode Diffuse Reflective Model No. E3FA-DP23 Brand Omron Product Type Sensor Ambient temperature range (Operating) -25 ....... 55 C Ambient humidity range (Operating) -40 ......... 70 C Weight 10 g Sensor type Photoelectric Sensor Weight 20 g Shape Cylinder type Shape Cylinder type Sensing method Diffuse-reflective Sensing distance White paper 300 x 300 mm: 1 m Spot size 120 x 150 mm (sensing distance: 1 m) Differential distance 20% max. Light source Red LED (624 nm) Power supply voltage 10 to 30 VDC±10% ripple (p-p) 10% included Current consumption 25 mA max. Control output PNP open collector 30 VDC max. 100 mA max. Residual voltage: 3 V max.
