E3JK-5M1 Omron Photoelectric Sensor

Material ABS Model No. E3JK-5M1 Brand Omron Product Type Sensor Product Type Photoelectric Sensor Power 1.5 A Color Black Weight 200 g Sensing distance 10 g Item Model E3JM-10@4(T)-N E3JM-R4@4(T) E3JM-DS70@4(T) Sensing distance 10 m 4 m (When using E39-R1) White paper (200 × 200 mm): 700 mm Standard sensing object Opaque: 14.8-mm dia. min. Opaque: 75-mm dia. min. --- Differential travel --- 20% max. of sensing distance Directional angle Both Emitter and Receiver 3° to 20° 1° to 5° --- Light source (wavelength) Infrared LED (950 nm) Red LED (660 nm) Infrared LED (950 nm) Power supply voltage 12 to 240 VDC±10%, ripple (p-p): 10% max. 24 to 240 VAC±10%, 50/60 Hz Power consumption DC 3 W max. (Emitter 1.5 W max. Receiver 1.5 W max.) 2 W max. AC 3 W max. (Emitter 1.5 W max. Receiver 1.5 W max.) 2 W max. Control output Relay output (E3JM-@@M4 (T) model): SPDT, 250 VAC, 3A (cos?=1) max., 5 VDC, 10 mA min. DC SSR output (E3JM-@@S4 (T) model): 48 VDC, 100 mA max. (residual voltage: 2 V max.) Light-ON/Dark-ON selectable Life expectancy (relay output) Mechanical 50,000,000 times min. (switching frequency: 18,000 times/h) Electrical 100,000 times min. (switching frequency: 1,800 times/h) Response time Relay output (E3JM-@@M4 (T) models) Operate or reset: 30 ms max. DC SSR output (E3JM-@@S4 (T) models) Operate or reset: 5 ms max.
