E3JK-DN11-C Omron Photoelectric Sensor

Material PVC Model no. E3JK-DN11-C Brand Omron Product type Sensor Sensor Type Photoelectric Sensor Weight 160 g Voltage 10 ...... 30 V Ambient temperature range -25 ...... 55 C Current 30 mA Shape Square type Sensing method Diffuse-reflective Sensing distance White paper 300 x 300 mm: 2.5 m Differential distance 20% max. of sensing distance Light source Red LED (624 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption 30 mA max. Control output NPN open collector 30 VDC max. 100 mA max. Residual voltage: 3 V max.
