E3JK-DR11 Omron Photoelectric Sensor

Material ABS Model No. E3JK-DR11 Brand Omron Product Type Sensor Sensor type Photoelectric Sensor Accuracy 100 % Ambient temperature range (Operating) -25 ......... +55 C Ambient temperature range (Storage) -40 .......... +70 C Response time 20 ms Control output 250 V E3JK-DR11 Omron Photoelectric sensor Shape Square type Sensing method Diffuse-reflective Sensing distance White paper 300 x 300 mm: 2.5 m Differential distance 20% max. of sensing distance Light source Red LED (624 nm) Power supply voltage 24 to 240 VAC±10% 50/60 Hz 24 to 240 VDC±10% ripple (p-p) 10% max. Power consumption 2 W max. Control output Relay output (SPDT) 250 VAC 3 A (cos?= 1) max. 5 VDC 10 mA min
