E3JK-RP12 Omron Photoelectric Sensor

Material ABS Model No. E3JK-RP12 Brand Omron Product Type Sensor Sensor Type E3JK-RP12 Weight 160 g Accuracy 100 % Color Black Response time 1 ms E3JK-RP12 Omron Photoelectric sensor Shape Square type Sensing method Retro-reflective with M.S.R. function Sensing distance When using the E39-R1: 100 mm to 6 m When using the E39-R2: 100 mm to 10 m Standard sensing object Opaque: 75 mm dia. min. Directional angle 1.5 ° min. Light source Red LED (624 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption 30 mA max. Control output PNP open collector 30 VDC max. 100 mA max. Residual voltage: 3 V max.
