E3JK-RR13 Omron Photoelectric Sensor

Material PVC Model No. E3JK-RR13 Brand Omron Product Type Sensor Sensor Type Photoelectric Sensor Color Black Protection IP64 Response time 20 ms E3JK-RR13 Omron Photoelectric sensor Shape Square type Sensing method Retro-reflective without M.S.R. function Sensing distance When using the E39-R1: 100 mm to 7 m When using the E39-R2: 100 mm to 11 m Standard sensing object Opaque: 75 mm dia. min. (When using the E39-R1) Opaque: 100 mm dia. min. (When using the E39-R2) Directional angle 1.5 ° min. Light source Infrared LED (850 nm) Power supply voltage 24 to 240 VAC±10% 50/60 Hz 24 to 240 VDC±10% ripple (p-p) 10% max. Power consumption 2 W max. Control output Relay output (SPDT) 250 VAC 3 A (cos?= 1) max. 5 VDC 10 mA min.
