E3JK-TP11 Omron Photoelectric Sensor

Material PVC Model No. E3JK-TP11 Brand Omron Product Type Sensor Sensor Type Photoelectric Sensor Control output PNP Protection IP64 Weight 350 g Accuracy 100 % E3JK-TP11 Omron Photoelectric sensor Shape Square type Sensing method Through-beam type Sensing distance 40 m Standard sensing object Opaque: 17 mm dia. min. Directional angle Emitter: 3 ° min. Receiver: 3 ° min. Light source Red LED (624 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption Emitter: 25 mA max. Receiver: 15 mA max. Control output PNP open collector 30 VDC max. 100 mA max. Residual voltage: 3 V max.
