E3JK-TR12 2M Omron Photoelectric Sensor

Sensor Type Through-Beam Sensing Mode Through Beam Sensing Distance 5 M Brand Omron Model E3JK-TR12 2M Standard sensing object Opaque: 17 mm dia. min. Light source Red LED (624 nm) Degree of protection IP64 Response time 20 ms max. Omron E3JK-TR12 2M Photoelectric Sensor Through-beam 5M Sensing Distance 24 to 240V AC/DC Type Red LED (624 nm) Pre-wired Model ABS, Omron Sensor Set E3JK-TR12 2M Specification/Additional Details Sensing Mode : Through Beam Sensing Distance : 5M Brand : Omron Model : E3JK-TR12 2M Standard sensing object : Opaque: 17 mm dia. min. Light source : Red LED (624 nm) Power supply voltage : 24 to 240 VAC+-10% 50/60 Hz / 24 to 240 VDC+-10% ripple (p-p) 10% max. Control output : Relay output (SPDT) 250 VAC 3 A max. 5 VDC 10 mA min. Operation mode : Light-ON/Dark-ON selectable Response time : 20 ms max. Sensitivity setting : Single-turn adjustment (Receiver only) Ambient illuminance : Incandescent lamp: 3,000 lx Sunlight: 11,000 lx Degree of protection : IEC: IP64 Connection method : Pre-wired models (Cable length 2 M)
