E3S-AD12 Omron Photoelectric Sensor

Material PBT Model No. E3S-AD12 Brand Omron Product Type Sensor Sensor type Photoelectric Sensor Current 30 mA Ambient temperature range (Storage) -40....... +70 C mbient temperature range (Operating) -25.........+55 C Voltage 10 - 30 V Accuracy 100 % Color Black Weight 90 g Protection IP67 Response time 0.5 ms E3S-AD12 Omron Photoelectric sensor Shape Square type Sensing method Diffuse-reflective Sensing distance White paper 200 x 200 mm: 700 mm Differential distance 20% max. of sensing distance Light source Infrared LED (850 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption 35 mA max. Control output NPN open collector 30 VDC max. 100 mA max. Residual voltage: 1 V max.
