E3S-AD633 Omron Photoelectric Sensor

Material PBT Model No. E3S-AD633 Brand Omron Product Type Sensor Sensor Type Photoelectric Sensor Color Black Sensing method Diffuse-reflective Sensing distance 100 mm Accuracy 100 % Application Industrial Control output NPN Shape Square type Sensing method Diffuse-reflective Sensing distance White paper 100 x 100 mm: 100 mm Differential distance 20% max. of sensing distance Light source Infrared LED (850 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption 35 mA max. Control output NPN open collector 30 VDC max. 100 mA max. Residual voltage: 1 V max. Operation mode Light-ON/Dark-ON selectable Protective circuit Output short-circuit protection, Power supply reverse polarity protection Response time Operate or reset: 0.5 ms max. Sensitivity setting 2-turn endless adjustment (with indicator) Ambient illuminance Incandescent lamp: 5,000 lx max. Sunlight: 10,000 lx max. Ambient temperature range (Operating) -25 to 55 ? (with no freezing or condensation)
