E3S-AT11 Omron Photoelectric sensor

Material ABS Model No. E3S-AT11 Brand Omron Product Type Sensor Sensor Type Photoelectric Sensor Voltage 10 ........ 30 V Accuracy 100 % Sensing distance 7 M Control output NPN Weight 150 g E3S-AT11 Omron Photo Shape Square type Sensing method Through-beam type Sensing distance 7 m Standard sensing object Opaque: 10 mm dia. min. Directional angle Emitter: 3 to 15 ° Receiver: 3 to 15 ° Light source Red LED (660 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption Emitter: 20 mA max. Receiver: 20 mA max. Control output NPN open collector 30 VDC max. 100 mA max. Residual voltage: 1 V max.
