E3S-AT16 Omron Photoelectric sensor

Material PBT Model No. E3S-AT16 Brand Omron Product type Sensor Sensor Type Photoelectric Sensor Color Black Weight 70 g Voltage 10 - 30 V Current 20 mA Ambient temperature range (Operating) -25 ........ +55 C Ambient temperature range (Storage) -40 ........ +70 C Sensing distance 7 m E3S-AT16 Omron Photoelectric sensor Shape Square type Sensing method Through-beam type Sensing distance 7 m Standard sensing object Opaque: 10 mm dia. min. Directional angle Emitter: 3 to 15 ° Receiver: 3 to 15 ° Light source Red LED (660 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption Emitter: 20 mA max. Receiver: 20 mA max. Control output NPN open collector 30 VDC max. 100 mA max. Residual voltage: 1 V max.
