E3S-CD61 Omron Photoelectric Sensor

Material ABS Model No. E3S-CD61 Brand Omron Product Type Sensor Sensor Type Photoelectric Sensor Weight 150 g Protection IP67 Ambient temperature range -25 ........ +55 C Control Output NPN Sensing method Diffuse-reflective Sensing distance 700 mm Current 40 mA Accuracy 100 % E3S-CD61 Omron Photoelectric sensor Shape Square type Sensing method Diffuse-reflective Sensing distance White paper 300 x 300 mm: 700 mm Differential distance 20% max. of sensing distance Light source Infrared LED (850 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption 40 mA max. Control output NPN/PNP open collector (selectable) 30 VDC max. 100 mA max. Residual voltage: 1.2 V max. (NPN output) Residual voltage: 2 V max. (PNP output)
