E3S-CL1 Omron Photoelectric Sensor

Sensing Mode Diffuse Reflective Material ABS Model No. E3S-CL1 Brand Omron Product Type Photoelectric Sensor Color Black Weight 170 g Voltage 10 ...... 30 V Temperature -25 ...... 55 C Sensing Distance 200 mm Shape Square type Sensing method Distance-setting Sensing distance White paper 200 x 200 mm, setting distance: 200 mm: 5 to 200 mm Setting range White paper 200 x 200 mm: 40 to 200 mm Differential distance 2% max. of setting distance Reflectivity characteristic (black-white error) 2% max. of setting distance Light source Red LED (660 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption 35 mA max. Control output NPN/PNP open collector (selectable) 30 VDC max. 100 mA max. Residual voltage: 1.2 V max. (NPN output) Residual voltage: 2 V max. (PNP output)
