E3S-CL2 Omron Photoelectric Sensor

Material ABS Model No. E3S-CL2 Brand Omron Product Type Sensor Sensor Type Photoelectric Sensor Color Grey Sensing distance 500 mm Voltage 10 - 30 V Current 50 mA Protection IP67 Control output NPN E3S-CL2 Omron Photoelectric sensor Shape Square type Sensing method Distance-setting Sensing distance White paper 200 x 200 mm, setting distance: 500 mm: 5 to 500 mm Setting range White paper 200 x 200 mm: 50 to 500 mm Differential distance 10% max. of setting distance Reflectivity characteristic (black-white error) 10% max. of setting distance Light source Infrared LED (850 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption 50 mA max. Control output NPN/PNP open collector (selectable) 30 VDC max. 100 mA max. Residual voltage: 1.2 V max. (NPN output) Residual voltage: 2 V max. (PNP output)
