E3S-CT61 Omron Photoelectric sensor

Material PBT Model No. E3S-CT61 Brand Omron Product Type Sensor Sensor Type Photoelectric Sensor Color Grey Current 100 mA Sensing distance 30 m Voltage 10 ....... 30 V Sensing method Through-beam type Accuracy 100 % E3S-CT61 Omron Photoelectric sensor Shape Square type Sensing method Through-beam type Sensing distance 30 m Standard sensing object Opaque: 15 mm dia. min. Directional angle Emitter: 3 to 15 ° Receiver: 3 to 15 ° Light source Infrared LED (850 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption Emitter: 25 mA max. Receiver: 25 mA max. Control output NPN/PNP open collector (selectable) 30 VDC max. 100 mA max. Residual voltage: 1.2 V max. (NPN output) Residual voltage: 2 V max. (PNP output)
