E3S-DCP21-IL3 Omron Photoelectric Sensor

Sensing Mode Diffuse Reflective Material ABS Model No. E3S-DCP21-IL3 Brand Omron Product type Photoelectric Sensor Shape Square type Sensing distance 13 mm Current 40 mA Control output 30 V Temperature -10 ..... 55 C Protection IP67 Shape Square type Sensing method Diffuse-reflective (mark detection) Sensing distance White paper 10 x 10 mm: 7 to 13 mm Spot size 1 x 4 mm Light source Red LED (635 nm) Green LED (525 nm) Blue LED (465 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption 40 mA max. Power consumption 960 mW max. Power supply voltage 24 V Control output Push-pull 30 VDC max. 100 mA max. Communications IO-Link Ver 1.1 COM3 (230.4 kbps) Data length: PD size: 8 bytes, OD size: 1 byte (M-sequence type: TYPE_2_2) Minimum cycle time: 1.5 ms
