E3S-LS20XB4 Omron Photoelectric Sensor

Material ABS Model No. E3S-LS20XB4 Brand Omron Product Type Sensor Sensor Type Photoelectric Sensor Weight 80 g Accuracy 100 % Respons Time 1 ms Voltage 12 - 24 V Protection IP67 Control Output NPN Frequency 50 Hz Control output Load power supply voltage: 24 VDC max., Load current: 100 mA max., (Residual voltage: 1 V max. for NPN output or 2 V max. for PNP output) Open collector output configuration: NPN or PNP output depending on the model, Operating mode: Light-ON Protection circuits Power supply reverse polarity protection, Output short-circuit protection, Mutual interference prevention Response time Operate or reset: 1 ms max. Timer function (only models with timer function) OFF-delay range: 0.1 to 1.0 s (adjustable) Ambient illumination (Receiver side) Incandescent lamp: 5,000 lux max. Ambient temperature range Operating: ?10 to 55°C (with no icing or condensation) Storage: ?25 to 70°C (with no icing or condensation) Ambient humidity range Operating: 35% to 85% (with no condensation) Storage: 35% to 95% (with no condensation) Insulation resistance 20 M? min. (at 500 VDC) Dielectric strength 1,000 VAC at 50/60 Hz for 1 minute Vibration resistance Destruction: 10 to 55 Hz with a 1.5-mm double amplitude for 2 hrs each in X, Y and Z directions Shock resistance Destruction: 500 m/s2, 3 times each in X, Y and Z directions Degree of protection IEC 60529 IP40 Connection method Pre-wired (standard length: 2 m) Weight (packed state) Approx. 80 g
