E3T-FL11 Omron Photoelectric sensor

Material PBT Model No. E3T-FL11 Brand Omron Product Type Sensor Sensor Type Photoelectric Sensor Weight 20 g Color Black Accuracy 100 % Ambient temperature range -25 ........ +55 C Control Output NPN Shape Rectangular type (Flat) Sensing method BGS reflective Sensing distance White paper 50 x 50 mm: 1 to 15 mm Minimum sensing object 0.15 mm min. dia. (non-glossy object, sensing distance: 10 mm) Differential distance 0.5 mm max. Reflectivity characteristic (black-white error) 15% max. Light source Red LED (650 nm) Power supply voltage 12 to 24 VDC±10% ripple (p-p) 10% max. Current consumption 20 mA max. Control output NPN open collector 26.4 VDC max. 50 mA max. Residual voltage: 1 V max. (Load current Less than 10 mA) Residual voltage: 2 V max. (Load current 10 to 50 mA)
