E3X-DA41 Omron Fiber Optic Sensor

Voltage 10-30V Brand Omron Type Fiber Optics Sensor Heads Interface IO-Link Model Number E3X-DA41 Switching Frequency 50 kHz Switching Output PNP Housing M8 Housing Material Plastic Degree of Protection IP67 Operating Temperature -40 to 125 Deg C No Load Supply Current 15 mA Supply voltage UB 12 ...... 24 V Device Short Name E3X-DA41 Model No. E3X-DA41 Product Type Sensor Sensor type Fiber Optic Sensor Temperature -15 ...... +55 C Weight 120 g Current 2.5 mA Accuracy 100 % Ambient illumination (receiver side) Incandescent lamp: 10,000 lx max. Sunlight: 20,000 lx max. Ambient temperature Operating: Groups of 1 to 3 Amplifiers: - 25 to 55°C Groups of 4 to 11 Amplifiers: - 25 to 50°C Groups of 12 to 16 Amplifiers: - 25 to 45°C Storage: - 30 to 70°C (with no icing or condensation) Ambient humidity Operating and storage: 35% to 85% (with no condensation) Insulation resistance 20 M? min. (at 500 VDC) Dielectric strength 1,000 VAC at 50/60 Hz for 1 min Vibration resistance (destruction) 10 to 55 Hz with a 1.5-mm double amplitude for 2 h each in X, Y and Z directions Shock resistance (destruction) 500m/s2, for 3 times each in X, Y and Z directions Degree of protection IEC IP50 (with Protective Cover attached) IEC IP66 (with Protective Cover attached) IEC IP50 (with Protective Cover attached) Connection method Pre-wired (standard cable length: 2 m) Weight (packed state) Approx. 100 g Approx. 110 g Approx. 100 g Materi- al Case Polybutylene terephthalate (PBT) Cover Polycarbonate Polyethersul- fone
