E3Z-B81 Omron Photoelectric Sensor

Material PBT Sensing Mode Retroreflective Model No. E3Z-B81 Brand Omron Product Type Sensor Sensor type Photoelectric Sensor Color Black Sensing Distance 80 to 500 mm Shape Square type Control output 100 mA max Ambient temperature range (Operating) -25 ....... 55 C Ambient temperature range (Storage) -40 ........ 70 C Weight 65 g Shape Square type Sensing method Retro-reflective without M.S.R. function Sensing distance When using the E39-R1S: 80 to 500 mm Standard sensing object Opaque: 75 mm dia. min. Glass tube (15 mm dia. thickness: 1.1 mm length: 50 mm, transmission factor 92% or less in wave length 660 nm) Light source Red LED (660 nm) Power supply voltage 12 to 24 VDC±10% ripple (p-p) 10% max. Current consumption 30 mA max. Control output PNP open collector 26.4 VDC max. 100 mA max. Residual voltage: 1 V max. (Load current Less than 10 mA) Residual voltage: 2 V max. (Load current 10 to 100 mA)
