E3Z-D62 Omron Photoelectric Sensor

Sensing Mode Diffuse Reflective Material PBT Model No. E3Z-D62 Brand Omron Product Type Photoelectric Sensor Shape Square type Sensing distance 1 m Voltage 12 - 24 V Temperature -25 .......... 55 C Current 30 mA Shape Square type Sensing method Diffuse-reflective Sensing distance White paper 300 x 300 mm: 1 m Differential distance 20% max. of sensing distance Light source Infrared LED (860 nm) Power supply voltage 12 to 24 VDC±10% ripple (p-p) 10% max. Current consumption 30 mA max. Control output NPN open collector 26.4 VDC max. 100 mA max. Residual voltage: 1 V max. (Load current Less than 10 mA) Residual voltage: 2 V max. (Load current 10 to 100 mA)
