E3Z-D81 Omron Photoelectric Sensor

Material PBT Sensing Mode Diffuse Reflective Model No. E3Z-D81 Brand Omron Product type Sensor Sensor Type Photoelectric Sensor Voltage 12 -24 V Weight 65 g Temperature -25 ....... 55 C Current 15 mA Shape Square type Light source Infrared LED (860 nm) Sensing method Diffuse-reflective Shape Square type Sensing method Diffuse-reflective Sensing distance White paper 100 x 100 mm: 100 mm Differential distance 20% max. of sensing distance Light source Infrared LED (860 nm) Power supply voltage 12 to 24 VDC±10% ripple (p-p) 10% max. Current consumption 30 mA max. Control output PNP open collector 26.4 VDC max. 100 mA max. Residual voltage: 1 V max. (Load current Less than 10 mA) Residual voltage: 2 V max. (Load current 10 to 100 mA)
