E3Z-D86 Omron Photoelectric Sensor

Sensing Mode Diffuse Reflective Material PBT Model No. E3Z-D86 Brand Omron Product Type Photoelectric Sensor Weight 20 g Color Black Voltage 12- 24 V Temperature -40 ....... 70 C Shape Square type Sensing method Diffuse-reflective Sensing distance White paper 100 x 100 mm: 100 mm Differential distance 20% max. of sensing distance Light source Infrared LED (860 nm) Power supply voltage 12 to 24 VDC±10% ripple (p-p) 10% max. Current consumption 30 mA max. Control output PNP open collector 26.4 VDC max. 100 mA max. Residual voltage: 1 V max. (Load current Less than 10 mA)
