E3Z-LR61 Omron Photoelectric Sensor

Material PBT Model No. E3Z-LR61 Brand Omron Product Type Sensor Sensor Type Photoelectric Sensor Color Black Weight 65 g Accuracy 100 % Application Industrial Voltage 12 ....... 24 V Sensing distance 7 m Shape Square type Sensing method Retro-reflective with M.S.R. function Sensing distance When using the E39-R12: 0.2 to 7 m Spot size 5 mm dia. max. (sensing distance: 3 m) Standard sensing object Opaque: 75 mm dia. min. Minimum sensing object 6 mm min. dia. (at 3 m) Light source Red LD (655 nm) Classification of laser IEC: Class 1 FDA: Class 1 JIS: Class 1 Power supply voltage 12 to 24 VDC±10% ripple (p-p) 10% max. Current consumption 30 mA max. Control output NPN open collector 26.4 VDC max. 100 mA max. Residual voltage: 1 V max. (Load current Less than 10 mA) Residual voltage: 2 V max. (Load current 10 to 100 mA
