E3Z-LS66 Omron Photoelectric Sensor

Material PBT Sensing Mode Through Beam Model no. E3Z-LS66 Brand Photoelectric Sensor Shape Square type Product Type Sensor Sensor Type Photoelectric Sensor Sensing distance 200 mm Connection method M8 Color Black Weight 20 g Current 30 mA Temperature -40 ........ 70 C Shape Square type Sensing method Distance-setting Sensing distance 20 to 200 mm Setting range White paper 100 x 100 mm: 40 to 200 mm Black paper 100 x 100 mm: 40 to 160 mm Detection range BGS: 20 mm to Setting distance (White paper, Black paper 100 x 100 mm) FGS: Setting distance to 200 mm min. (White paper 100 x 100 mm), Setting distance to 160 mm min. (Black paper 100 x 100 mm) Differential distance 10% max. of setting distance Reflectivity characteristic (black-white error) 10% max. of setting distance Light source Red LED (670 nm) Power supply voltage 12 to 24 VDC±10% ripple (p-p) 10% max. Current consumption 30 mA max. Control output NPN open collector 26.4 VDC max. 100 mA max. Residual voltage: 1 V max.
