E3Z-LS83 Omron Photoelectric Sensor

Material PBT Sensing Mode Diffuse Reflective Model No. E3Z-LS83 Brand Omron Product type Sensor Voltage 10 - 30 V Temperature -25 ....... 55 C Weight 65 g Sensing distance 2 - 80 mm Setting range 25 x 25 - 20 to 80 mm Shape Square type Sensing method Distance-setting Sensing distance 2 to 80 mm Setting range White paper 25 x 25 mm: 20 to 80 mm Detection range 2 mm to Setting distance (80 mm max.) Differential distance 2% max. of setting distance Reflectivity characteristic (black-white error) 5% max. of setting distance Light source Red LED (650 nm) Power supply voltage 12 to 24 VDC±10% ripple (p-p) 10% max. Current consumption 30 mA max. Control output PNP open collector 26.4 VDC max. 100 mA max.
