E3Z-LS88 Omron Photoelectric Sensor

Sensing Mode Through Beam Material PBT Model No. E3Z-LS88 Brand Omron Product Type Photoelectric Sensor Sensing distance 2 - 80 mm Shape Squar type Color Black Setting range 25 x 25 mm: 20 to 80 mm Shape Square type Sensing method Distance-setting Sensing distance 2 to 80 mm Setting range White paper 25 x 25 mm: 20 to 80 mm Detection range 2 mm to Setting distance (80 mm max.) Differential distance 2% max. of setting distance Reflectivity characteristic (black-white error) 5% max. of setting distance Light source Red LED (650 nm) Power supply voltage 12 to 24 VDC±10% ripple (p-p) 10% max. Current consumption 30 mA max. Control output PNP open collector 26.4 VDC max. 100 mA max. Residual voltage: 1 V max.
