E3Z-R66 Omron Photoelectric Sensor

Sensing Mode Retroreflective Material PBT Model No. E3Z-R66 Brand Omron Product Type Photoelectric Sensor Weight 20 g Temperature -40 ..... 85 C Protection IP67 Control output NPN Light source Red LED Shape Square type Sensing method Retro-reflective with M.S.R. function Sensing distance When using the E39-R1S: 100 mm to 4 m When using the E39-R1: 100 mm to 3 m Standard sensing object Opaque: 75 mm dia. min. Directional angle 2 to 10 ° Light source Red LED (660 nm) Power supply voltage 12 to 24 VDC±10% ripple (p-p) 10% max. Current consumption 30 mA max. Control output NPN open collector 26.4 VDC max. 100 mA max. Residual voltage: 1 V max. (Load current Less than 10 mA) Residual voltage: 2 V max. (Load current 10 to 100 mA)
