E3ZM-V66 Omron Photoelectric Sensor

Sensing Mode Diffuse Reflective Material PBT Model No. E3ZM-V66 Brand Omron Product type Sensor Sensing method Diffuse-reflective Sensing distance 10 to 14 mm Connection method M8 connector models Weight 35 g Control output NPN (100 mA) Sensor Type Photoelectric Sensor Temperature -40 ......... 70 C Shape Square type Sensing method Diffuse-reflective (mark detection) Sensing distance 10 to 14 mm Spot size 2 mm dia. max. Light source White LED (450 to 700 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption 25 mA max. Power consumption 750 mW max. (30 VDC) Control output NPN open collector 30 VDC max. 100 mA max. Residual voltage: 2 V max.
