E40258 IFM Progressive Ring Fitting

Installation Progressive ring fitting Pressure rating 50 bar 5 MPa Tests / approvals Pressure Equipment Directive A possible classification to PED depends on the application and has to be carried out by the user / operator. Safety instructions The compatibility between medium and product material has to be checked in all applications. Mechanical data Weight[g] 100.8 Materials stainless steel (316L/1.4404); Gasket: FKM Sensor connection Ø 8 mm Process connection threaded connection G 1/2 Accessories Items supplied Gasket For a quick and easy mounting of temperature sensors User-friendly setting of the requested immersion depth of the sensor Robust stainless steel design for use in harsh industrial environments High pressure rating
