E40H6-360-3-T-24 Autonics Rotary Encoder

Material Stainless Steel Encoder Type Rotary Usage/Application Industrial Color Silver Power Supply Voltage 5 V Operating Temperature Range -10 ..... 70 V Storage Temperature Range 70 C Total Resolution 360 P/R Weight (packed state) 120 g Model No. E40H6-360-3-T-24 Brand Autonics Product type Rotary Encoder Voltage 12- 24 V Protection IP50 Output phase A , B , Z Shaft inner diameter : Ø6mm Max. response frequency : 300kHz Max. allowable revolution : 5000rpm Starting torque : Max. 50gf.cm(max. 0.0049N.m) Resolution : 360P/R Control output : Totem pole Power supply : 12-24VDC ±5%(ripple P-P: max. 5%) Connection type : Radial cable type Protection structure : IP50
