E40H8-360-3-T-24 Autonics Incremental Rotary Encoder

Encoder Type Rotary Material Stainless Steel Usage/Application Industrial Color Silver Hollow Shaft Diameter 8 mm Power Supply Voltage 12 ...... 24 V Operating Temperature Range -25 ....... 70 C Storage Temperature Range 70 C Weight (packed state) 120 g Model No. E40H8-360-3-T-24 Product Type Incremental Rotary Encoders Max. response frequency 300 kHz Max. allowable revolution 5000 rpm E40H8-360-3-T-24 Shaft inner diameter : Ø8mm Max. response frequency : 300kHz Max. allowable revolution : 5000rpm Starting torque : Max. 50gf.cm(max. 0.0049N.m) Resolution : 360P/R Control output : Totem pole Power supply : 12-24VDC ±5%(ripple P-P: max. 5%) Connection type : Radial cable type Protection structure : IP50
