E40H8-360-6-L-5 Autonics Hollow Shaft Encoder

Diameter 8 mm Brand Autonics Encoder Type Rotary Encoder Color Silver Usage/Application Industrial Model Name/Number E40H8-360-6-L-5 Material PBT Protection Class IP50 Temperature -25 ........ 70 C Type Encoder Voltage 12 ..... 24 V Model No. E40H8-360-6-L-5 E40H8-360-6-L-5 Shaft inner diameter : Ø8mm Max. response frequency : 300kHz Max. allowable revolution : 5000rpm Starting torque : Max. 50gf.cm(max. 0.0049N.m) Resolution : 360P/R Control output : Line Driver Power supply : 5VDC ±5%(ripple P-P: max. 5%) Connection type : Radial cable type Protection structure : IP50
