E40H8-500-6-L-5 Autonics Hollow Shaft Encoder

Diameter 8 mm Brand Autonics Encoder Type Rotary Encoder Color Silver Usage/Application Industrial Model Name/Number E40H8-500-6-L-5 Material PBT Current Rating 15 mA Protection Class IP50 Temperature -25 .... 70 C Type Rotary Encoder Voltage 12 .... 24 V Weight 120 g E40H8-500-6-L-5 Shaft inner diameter : Ø8mm Max. response frequency : 300kHz Max. allowable revolution : 5000rpm Starting torque : Max. 50gf.cm(max. 0.0049N.m) Resolution : 500P/R Control output : Line Driver Power supply : 5VDC ±5%(ripple P-P: max. 5%) Connection type : Radial cable type Protection structure : IP50
