E40S6-1024-3-T-24 AUTONICS Incremental Rotary Encoder

Usage/Application Industrial Color Black Hollow Shaft Diameter 6 MM Power Supply Voltage 12-24 VDC Pulse Per Revolution (PPR) 1024 PPR Weight (packed state) Approx 120 g Max. response frequency 300kHz Max. allowable revolution 5000rpm Protection structure IP 50 Connection type Radial cable type Shaft outer diameter Ø6mm Max. response frequency 300kHz Max. allowable revolution 5000rpm Starting torque Max. 40gf.cm(max. 0.00392N.m) Resolution 1024P/R Output phase A, B, Z Control output Totem pole Power supply 12-24VDC ±5%(ripple P-P: max. 5%) Connection type Radial cable type Protection structure IP50 Environment_Ambient temperature -10 to 70?, storage: -25 to 85? Environment_Ambient humidity 35 to 85% RH, storage: 35 to 90% RH Accessories Ø6mm coupling standard, Ø8mm coupling(sold separately) Weight Approx. 120g
