E40S8-400-3-N-24 Autonics Rotary Encoder

Encoder Type Rotary Material Stainless Steel Usage/Application Industrial Color Black Hollow Shaft Diameter 8 mm Power Supply Voltage 12 - 24 V Operating Temperature Range -10 ......... +70 C Storage Temperature Range -25 .......... +55 C Total Resolution 400P/R Weight (packed state) 120 g Model No. E40S8-400-3-N-24 Brand Autonics Product Type Rotary Encoders Accuracy 100 % Max. response frequency 300kHz Max. allowable revolution 5000rpm Protection structure IP50 E40S8-400-3-N-24 Shaft outer diameter : Ø8mm Max. response frequency : 300kHz Max. allowable revolution : 5000rpm Starting torque : Max. 40gf.cm(max. 0.00392N.m) Resolution : 400P/R Control output : NPN open collector Power supply : 12-24VDC ±5%(ripple P-P: max. 5%) Connection type : Radial cable type Protection structure : IP50
