E58HB12-1000-6-L-5-CS Autonics Rotary Encoder

Encoder Type Rotary Material Stainless Steel Usage/Application Industrial Color Silver Operating Temperature Range -10.....55 C Model No. E58HB12-1000-6-L-5-CS Brand Autonics Type Rotary Encoder Protection IP 50 Shaft inner diameter 12 Weight 90 g E58HB12-1000-6-L-5-CS Shaft inner diameter : Ø12mm Max. response frequency : 300kHz Max. allowable revolution : 5000rpm Starting torque : Max. 90gf.cm(max. 0.00882N.m) Resolution : 1000P/R Control output : Line Driver Power supply : 5VDC ±5%(ripple P-P: max. 5%) Connection type : Radial connector type Protection structure : IP50
