EE-SX675 Omron Micro Photoelectric Sensor

Material PBT Model No. EE-SX675 Brand Omron Product Type Sensor Sensor Type Photoelectric Sensor Color Black Weight 2.7 g Accuracy 100 % Control Output VDC Sensing distance 5 mm Type Grooved Type (T-shaped) (Slot center 10 mm) Luminous method Non-modulated Sensing method Through-beam type Sensing distance Slot width: 5 mm Operation mode Dark-ON/Light-ON (selectable) Standard sensing object Opaque, 2 x 0.8 mm min. Differential distance elements 0.025 mm max. Light source ?Peak wavelength? Infrared LED (940 nm) Indicator Light indicator (red) Power supply voltage 5 to 24 VDC ±10% ripple (p-p) 10 % max. Current consumption 12 mA (L terminal open) Control output Output type NPN open collector output Load power supply voltage 5 to 24 VDC Load curren 100 mA max. Residual voltage at 100 mA load current: 0.8 V max. at 40 mA load current: 0.4 V max. Protection circuits Output short-cut protection
