EX-28A-PN Panasonic Photoelectric Sensor

Material PBT Accuracy 100 % Activation current 15 mA Active Area 10 mm Operating temperature -25 .... +55 C Model No. EX-28A-PN Brand Panasonic Product Type Sensor Sesnor type Photoelectric Sensor Weight 45 g Output PNP Current 15 mA Product Number EX-28A-PN Part Number EX-28A-PN Products Name Ultra-compact Photoelectric Sensor Product details Narrow-view reflective(Long distance spot beam type)[Side sensing] The price of the product Please contact our office Applicable regulations CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations) Sensing range 45 to 115 mm 1.772 to 4.528 in with white non-glossy paper (100 x 100 mm 3.937 x 3.937 in), spot diameter dia. 5 mm dia. 0.197 in with setting distance 80 mm 3.150 in Sensing object Opaque, translucent or transparent object (Note) (Min. dia. 1 mm dia. 0.039 in copper wire at setting distance 80 mm 3.150 in) (Note) Make sure to confirm detection with an actual sensor before use. Hysteresis 15 % or less of operation distance [100 x 100 mm 3.937 x 3.937 in with white non-glossy paper] Repeatability(perpendicular to sensing axis) 0.3 mm 0.012 in or less
