EX-Z11FB-R Panasonic Photoelectric Sensor

Material PBT Accuracy 100 % Activation current 15 mA Active Area 10 mm Operating temperature -25 ........ 80 C Model No. EX-Z11FB-R Brand Panasonic Weight 20 g Supply Voltage 12 ....... 24 V Item Performance characteristics CE Marking Directive Compliance EMC Directive, RoHS Directive Output Operation Dark-ON Sensing Range 50 mm 1.969 in Min. Sensing Object ø0.3 mm ø0.012 in opaque object (Completely beam interrupted object)(Setting distance between emitter and receiver: 50 mm 1.969 in) Repeatability (Perpendicular to Sensing Axis) 0.02 mm 0.001 in or less
