EX-Z13A Panasonic Photoelectric Sensor

Material PBT Accuracy 100 % Activation current 15 mm Active Area 10mm Operating temperature -25 ....... 55 C Model no. EX-Z13A Brand Panasonic Product Type Sensor Sensor Type Photoelectric Sensor Color Black Weight 35 g Protection IP67 Cable Length 2 m Product Number EX-Z13A Part Number EX-Z13A Products Name Ultra-minute Photoelectric Sensor Product details Thru-beam [Side sensing] Applicable regulations and certifications CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations), UL/c-UL Certification Output operation Light-ON Sensing range 500 mm 19.685 in Min. sensing object ø1.0 mm ø0.039 in opaque object (Completely beam interrupted object)(Setting distance between emitter and receiver: 500 mm 19.685 in) Repeatability(perpendicular to sensing axis) 0.05 mm 0.002 in or less
