FX-311-P Panasonic Fiber Optic Sensor

Voltage 10-30V Brand Panasonic Type Fiber Optics Sensor Heads Light Source Infrared LED Interface IO-Link Model Number FX-311-P Switching Frequency 500 Hz Switching Output PNP Housing M8 Housing Material Stainless Steel Degree of Protection IP67 Operating Temperature -40 to 125 Deg C No Load Supply Current 50 C Supply voltage UB 10 ....... 30 V Device Short Name Panasonic Fiber Optic Sensor Weight 15 g Voltage withstandability 1000 V Sernsor Type Fiber Optic Sensor Product Type Fiber Optic Sensor ations and design of the products are subject to change without notice for the product improvement. Item Specifications Product Number FX-311P Part Number FX-311P Products Name Manually Set Fiber Sensor Product details PNP output Supply voltage 12 to 24 V DC ±10 % Ripple P-P 10 % or less Power consumption 840 mW or less (Current consumption 35 mA or less at 24 V supply voltage)
