FX-551P-C2 Panasonic Digital Fiber Sensor

Voltage 10-30V Brand Panasonic Type Optical Fiber Amplifier Light Source Red LED Interface IO-Link Model Number FX-551P-C2 Switching Frequency 50 Hz Switching Output PNP Housing Material Plastic Operating Temperature -40 to 125 Deg C Supply voltage UB 10 - 24 V Protection IP40 Cable 2 m Item Performance characteristics CE Marking Directive Compliance EMC Directive, RoHS Directive Supply Voltage 12 to 24 V DC +10-15 % Ripple P-P 10 % or less Power Consumption Normal operation : 960 mW or less (current consumption 40 mA or less at 24 V supply voltage) ECO mode : 680 mW or less (current consumption 28 mA or less at 24 V supply voltage) Output PNP open-collector transistor ?Maximum source current : 100 mA ?Applied voltage : 30 V DC or less (between output and +V) ?Residual voltage : 2 V or less (at maximum source current)
