G2RV-ST700-DC24 Omron Slim Relay

Number Of Poles 4 Pole Material Plastic Usage/Application Control Panels Model Name/Number G2RV-ST700-DC24 Coil Voltage 10 - 30 V Voltage Type AC Current 13.5 mA Relay Type Signal Relays Brand Omron Weight 30 g Accuracy 100 % Coil ratings 24 VDC 13.5 mA Performance Contact resistance 100 m? max. (at 23 ?) Operating time 20 ms max. (23 ?) Reset time 20 ms max. (23 ?) Maximum operating frequency Mechanical: 18000 time/hour Electrical: 1800 time/hour Insulation resistance 1000 M? min. (at 500 VDC) Dielectric strength Between coil and contacts: 4000 VAC 50/60 Hz 1 min Between contacts of same polarity: 1000 VAC 50/60 Hz 1 min Vibration resistance (destruction) 10 to 55 to 10 Hz, 0.5-mm single amplitude (1-mm double amplitude) Vibration resistance (Malfunction) 10 to 55 to 10 Hz, 0.5-mm single amplitude (1-mm double amplitude) Shock resistance (destruction) 1000 m/s2 Shock resistance (Malfunction) Energized: 200 m/s2 No energized: 100 m/s2 Endurance (Mechanical) 5,000,000 operations min.
