GD100P1T120C6SN-G8 Semikron IGBT Module

Voltage 1200 V Brand Semikron Usage/Application AC Inverter Drives Mounting Type SMD Package Type Plastic Maximum Operating Temperature 125 c Model Name/Number GD100P1T120C6SN-G8 Weight 300 GD100PIY120C6SN1200V/100A PIM in one-packageGeneral DescriptionSTARPOWER IGBT Power Module provides ultralow conduction loss as well as short circuit ruggedness.They are designed for the applications such asgeneral inverters and UPS.Features? Low V CE(sat) Trench IGBT technology? 10?s short circuit capability? V CE(sat) with positive temperature coefficient? Maximum junction temperature 175oC? Low inductance case? Fast & soft reverse recovery anti-parallel FWD? Isolated copper baseplate using DBC technologyTypical Applications? Inverter for motor drive? AC and DC servo drive amplifier? Uninterruptible power supply
